ISO 7241 Series B Japanese Type Quick Coupling Nitto Type Connector
IKER’s multi-purpose Japanese type hydraulic quick coupling is engineered for seamless fluid transfer in industrial settings. With a robust poppet valve design and high flow capacity, this coupling ensures reliable performance in diverse applications. Crafted with precision, its quick connection mechanism simplifies integration into hydraulic systems. The interchangeable design offers versatility, while its durability guarantees long-lasting operation.
Features
- Poppet valves available to prevent uncoupled leakage.
- Poppet valves open automatially when coupled within rated working pressure, to keep the flow expeditely.
- Dependable ball-locking mechanism holds the mating halves together.
- KZD series conforms to the standard ISO7241-B.
Specifications of Multi-purpose Japanese Type Hydraulic Quick Coupling
| Model Number |
ZJ-KZD |
||||||||
| Material |
Brass |
||||||||
| Valve Type |
Poppet Type |
||||||||
| Body Size (In) | 1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1 | 11/4 | 11/2 | 2 |
| Rated Pressure (PSI) | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 800 | 800 | 800 |
| Rated Flow (GPM) | 1 | 3 | 6 | 12 | 28 | 50 | 75 | 100 | 150 |
| Temperature Range |
-20℃ to +100℃ |
||||||||
| Standard Seal Material |
NBR |
||||||||
| Interchange Standard |
· Parker 60 · Perfecting H · Faster HNV · Safeway S10 · Snap Tite’s 72 · Hansen HK · Aeroquip FD45 · DNP PBV · Stucchi IRB |
||||||||
Applications of Multi-purpose Japanese Type Hydraulic Quick Coupling
ZJ-KZD nitto quick couplings are used across the spectrum of hydraulic applications. These Double Shut-Off couplings can be found anywhere that fluid transfer lines need to be connected and disconnected for operation or maintenance of equipment, and a loss of fluid is undesirable. Primarily used with hydraulic fluid. This couplings are also used with chemicals, water, steam, and some gas.
Why Choose IKER’s Multi-purpose Japanese Hydraulic Multi Couplers ?
IKER (Jiangxi Aike Industrial Co., Ltd.), founded in 1992, has evolved into a leader in the hydraulic and pneumatic quick couplings industry. Located in Dongxiang, Jiangxi Province, our facilities have expanded to cover 30,000 square meters with an annual production capacity of over 3,000,000 pieces, meeting the robust demands of global markets.
Our commitment to delivering high-quality, reliable, and environmentally sound fluid connection solutions has garnered trust across various sectors such as oil, metallurgy, and agriculture, establishing strong partnerships in over 20 countries including the United States, France, and Australia.
Choose IKER for proven expertise and innovative products that drive efficiency and sustainability in your operations.
